micro pattern on circle

Posted Dec 17, 2018, 5:30 a.m. EST Structural & Acoustics, MEMS & Piezoelectric Devices 3 Replies

Usama Tahir
Send Private Message Flag post as spam

Please login with a confirmed email address before reporting spam

Hi i want to create micro rectangular pattern on circle circumference like the figure in the attached file, i need help regarding this.

Attachments:

3 Replies Last Post Dec 24, 2018, 9:19 a.m. EST
Jeff Hiller COMSOL Employee

Please login with a confirmed email address before reporting spam

Posted: 6 years ago Dec 17, 2018, 12:05 p.m. EST

Hello Usama,

The simplest is probably to use the Rotate feature with a range operator in the Rotation Angle field, see attached file.

Best,

Jeff

-------------------
Jeff Hiller
Hello Usama, The simplest is probably to use the Rotate feature with a range operator in the Rotation Angle field, see attached file. Best, Jeff

Attachments:

Usama Tahir
Send Private Message Flag post as spam

Please login with a confirmed email address before reporting spam

Posted: 6 years ago Dec 24, 2018, 3:10 a.m. EST

Helloo Dear Jeff. This file is not opening in Comsol 5.3.1 version it need latest version can you please send me this file in the version i have Regards Usama

Helloo Dear Jeff. This file is not opening in Comsol 5.3.1 version it need latest version can you please send me this file in the version i have Regards Usama
Jeff Hiller COMSOL Employee

Please login with a confirmed email address before reporting spam

Posted: 6 years ago Dec 24, 2018, 9:19 a.m. EST

I cannot offer to post in the Discussion Forum in older versions. Please consider updating to the current version.

Best,

Jeff

-------------------
Jeff Hiller
I cannot offer to post in the Discussion Forum in older versions. Please consider updating to the current version. Best, Jeff
