coupled PDEs, one 3D the other 2D with coupled boundary conditions
Posted Dec 15, 2020, 2:41 p.m. EST Fluid & Heat, Acoustics & Vibrations, Equation-Based Modeling Version 5.0 0 Replies
Please login with a confirmed email address before reporting spam
Hi community,
I'd like to know if I can use equation-based modelling to solve the coupled system of PDEs in the attached file. The unknowns are phi(t,x,y,z), eta(t, x,z), and p(t, x, z). Note that the time-dependance in the equations could be neglected (d/dt = 0).
Everything else in the equations are constants, except P(t, x, z) which could be coordinate-dependant, but not time dependant.
Cheers, Hossein
Attachments:
Hello Hossein Babaei
Your Discussion has gone 30 days without a reply. If you still need help with COMSOL and have an on-subscription license, please visit our Support Center for help.
If you do not hold an on-subscription license, you may find an answer in another Discussion or in the Knowledge Base.
