Piezo resistive pressure sensor with voltage divider
Posted Jan 31, 2022, 10:32 a.m. EST Electromagnetics, Piezoelectric Devices, Structural & Acoustics Version 5.5 0 Replies
Please login with a confirmed email address before reporting spam
Dear all, hope you can help me with my model!
I need to simulate a piezoresistive pressure sensor (non-shell) read via a voltage divider. I have combined the electric currents module with the solid mechanics module and have some questions: How can I simulate an analogue output(analog pin in the attached image)? how can i connect electrical circuit module to electrical currents module? I used the p-silicon material suggested by online examples.. attached the schematic of the electrical circuit
thank you very much for your kind help! Best wishes Florinda
