Cylinder Roller Contact
Application ID: 1431
Consider an infinitely long steel cylinder resting on a flat aluminum foundation, where both structures are elastic. The cylinder is subjected to a point load along its top. The objective of this study is to find the contact pressure distribution and the length of contact between the foundation and the cylinder. An analytical solution exists, and this model includes a comparison against the COMSOL Multiphysics solution. The contact pressure distribution and contact length are computed using the penalty method, both augmented Lagrangian methods, and the Nitsche method. This model is based on a NAFEMS benchmark.
This model example illustrates applications of this type that would nominally be built using the following products:
however, additional products may be required to completely define and model it. Furthermore, this example may also be defined and modeled using components from the following product combinations:
- COMSOL Multiphysics® and
- either the MEMS Module, Multibody Dynamics Module, or Structural Mechanics Module
