Solidly Mounted Resonator 2D with Uncertainty Quantification
Application ID: 114021
Uncertainty Quantification is used to study the effect of manufacturing variation on the performance of 2D Solidly Mounted Resonator (2D SMR). This tutorial shows how resonant frequency is effected by thickness variations of the piezoelectric layer and the Bragg reflector layers. The tutorial includes a technique for selecting the correct eigenmode to be used as Quantity of Interest in the Uncertainty Quantification studies.
This model example illustrates applications of this type that would nominally be built using the following products:
however, additional products may be required to completely define and model it. Furthermore, this example may also be defined and modeled using components from the following product combinations:
- COMSOL Multiphysics® and
- Uncertainty Quantification Module and
- either the Acoustics Module, MEMS Module, or Structural Mechanics Module and
- either the AC/DC Module, MEMS Module, Plasma Module, or Semiconductor Module
The combination of COMSOL® products required to model your application depends on several factors and may include boundary conditions, material properties, physics interfaces, and part libraries. Particular functionality may be common to several products. To determine the right combination of products for your modeling needs, review the Specification Chart and make use of a free evaluation license. The COMSOL Sales and Support teams are available for answering any questions you may have regarding this.
